Revit 2009 to 3ds Max 2009 Curriculum

One of the projects which I had the pleasure to work on recently, was for the Autodesk Media and Entertainment division's education department. The project entailed writing a short tutorial on the process involved in rendering a Revit 3D model in 3ds Max.

Now it's been several releases since you have been able to take a Revit Model, export it to DWG, and then Link / Import it into 3ds Max. In 2009, a new method of exporting and importing has been introduced using an FBX file.

The greatest advantage in using FBX is the amount of information which is now transfered from Revit to 3ds Max. Revit 2009 now has the mental ray rendering engine incorporated within it, and when you start the rendering procss in Revit, by assigning lights and materials, this information then gets transfered to 3ds Max....!!! ............SWEET............!!!

Through FBX, Revit metadata also gets transfered. Like the Revit Family, Category and Level. which you can use in 3ds Max to organize your models.

Through this improvement in Revit rendering technology, Autodesk appears to be recommending to designers to take their models and renderings as far as possible in Revit, and when ready transfer to 3ds Max for final renderings. Unfortunately, one of the things which is lacking at the moment is a complete resource of Revit components and families. Rendering elements like furniture and speciality Revit families like windows and doors typically are built from scratch by companies adopting Revit. This makes for a long and expensive implementation of the software.

Some help is available, as in the Revit content site,

http://revit.autodesk.com/library/html/index.html

Much more is needed.

Allways looking foward to better tools.
cheers
rec
